    Stadium Fixed Aluminum Sports Bleachers 430mm Seat Height With Double Foot Planks

    Ask Lasest Price
    Brand Name : Burgeon
    Model Number : fixed aluminum bleacher
    • Product Details
    • Company Profile

    Stadium Fixed Aluminum Sports Bleachers 430mm Seat Height With Double Foot Planks

    Stadium Fixed Aluminum Outdoor Bleacher with Double Foot Planks


    Specification

    ItemContentSpecifications
    Understructure
    1FramePrefabricated 50*5mm aluminum angle joined by means of aluminum angle cross bracing. Each frame shall be unit-welded, using metal inert gas method to form into trapezium shape.
    2BracingAdopt 40*5mm aluminum angle cross & horizontal bracing.
    3HardwareStainless bolts and nuts; Anodized Aluminum Alloy Cramp Bracket
    4Foot PadNon-marking rubber foot pads to protect wood floors.
    Decking & Accessories
    1Chief Deck240*40*3mm Anodized Aluminum Alloy 6063-T6 Foot Plank, extruded with a concave and convex grooves for impact and deformation resistance.
    2Vice Deck240*40*3mm Anodized Aluminum Alloy 6063-T6 Foot Plank, extruded with a concave and convex grooves for impact and deformation resistance. (Double Foot Planks)
    3Cramp BracketAnodized Aluminum Alloy Cramp Bracket
    Seat Option
    1Aluminum Seat Plank240*40*3mm Anodized Aluminum Alloy 6063-T6 Seat Plank, extruded with a concave and convex grooves for impact and deformation resistance. (Polymer Echo Seats are available)
    Basic Design Data
    1Design StandardBS 5950 Structural Use of Steelwork in Building; EN1991-1-3 for Assessment of Wind Load; BS6399 Part 2: Loading for Buildings-Code of Practice for Wind Loads.
    2DimensionDeck width:600mm/660mm; Riser height:150mm
    3Seat Height≥430mm
    4LoadVertical dead load for stand platform ≥350kg/m, Horizontal wavering load for stand platform ≥36kgm

    Features

    • Safety, easy assembly and durability
    • Light weight
    • The all-aluminum framwork is combined with anodized aluminum seat planks and mill-finished foot planks.
    • Fixed bleacher system requires little or no maintenance for years to come.
    • Fixed bleacher and portable bleacher are available

    FAQ

    1.Q: What kind of product range do you offer?

    A: Burgeon focus on spectator seating solution including fixed stadium seat, telescopic seating system, aluminum bleacher and metal bleacher.


    2.Q: What do I need to start an order?

    A: Normally give us product type, seating quantity, project drawing with PDF/Auto CAD format, then we can start to design

    and offer for you.


    3.Q: How long will I receive my product after ordered?

    A: It depend on the size of project order and the distance from loading port to destination port, our production lead time is

    normally 3-4 weeks after the order/payment is received.
